Honda Civic (2010 - 2011) - fuse box diagram Year of production: 2010, 2011 Engine Compartment Fuse Box Number Ampere rating [A] Circuits protected 1 100 Main Fuse 70 EPS*1 2 80 Option Main 50 Ignition Switch Main 3 30 ABS/VSA Motor 30 ABS/VSA F/S 40*2 4 50 Headlight Main 40 Power Window Main 5 …

Honda Civic (2010 – 2011) – fuse box diagram

Year of production: 2010, 2011

Engine Compartment Fuse Box Honda Civic – fuse box –engine compartmentNumber Ampere rating [A] Circuits safe 1 100 Main Fuse 70 EPS*1 2 80 Option Main 50 Ignition Switch Main 3 30 ABS/VSA Motor 30 ABS/VSA F/S 40*2 4 50 Headlight Main 40 Power Window Main 5 — Not Used 6 20 Sub Fan Motor 7 20 Main Fan Motor (M/T) 30 Main Fan Motor (A/T) 8 30 Rear Defogger 9 40 Blower 10 10 Hazard 11 15 FI Sub 12 15 Stop and Horn 13 — Not Used 14 — Not Used 15 7,5 IGPS Oil Level 16 — Not Used 17 15 Audio Amp*1 18 15 IG Coil 19 15 FI Main 20 7,5 MG Clutch 21 7,5 DBW 22 7,5 Interior Light 23 10 Back Up *1:  If equipped*2: On models with VSA gadget Interior Fuse Box Honda Civic – fuse box –interiorNumber Ampere ranking [A] Circuits safe 1 7,5 Power Window 2 15 Fuel Pump 3 10 Alternator 4 7,5 ABS/VSA 5 (15) Heated Seat* 6 (20) Front Fog Light* 7 (7,5) TPMS* 8 — Not Used 9 7,5 ODS 10 7,5 METER 11 10 SRS 12 10 Right Headlight High Beam 13 10 Left Headlight High Beam 14 7,5 Small Light (Interior) 15 7,5 Small Light (Exterior) 16 10 Right Headlight Low Beam 17 10 Left Headlight Low Beam 18 20 Headlight High Beam Main 19 15 Small Lights (Main) 20 — Not Used 21 20 Headlight Low Main 22 — Not Used 23 — Not Used 24 (20) Moonroof* 25 20 Door Lock 26 20 Driver's Power Window 27 — Not Used 28 (15) Rear Accessory Socket* 29 15 Accessory 30 20 Passenger's Power Window 31 — Not Used 32 20 Right Rear Power Window 33 20 Left Rear Power Window 34 — Not Used 35 7,5 Accessory Radio 36 10 HAC 37 7,5 Daytime Running Light 38 30 Power Wiper *: If provided

WARNING: Terminal and harness assignments for particular person connectors will range depending on automobile apparatus level, style, and market.
